Highlights
- Illuminant: 10 POWER LED / 5000K
- Protection tube: polycarbonate, shock-resistant, 40mm Ø
- Handle / end cap: PVC, black
- Metal hook: yes, rotatable
- Protection category: IP54 (optional IP65 - on request)
- Protection class: II respectively III
- Cable: 5m H05RN-F 2x1,00mm²
- Voltage: 230V / 110V / 42V / 24V
- Special models - longer cable, cable type, plug etc. on request.
Technical specifications
Technical Data KE-LED 4010-P (Profi)
|
| Illuminant |
10x Power LEDs / 5000 Kelvin |
| Power |
8 W |
| Luminous flux |
ca. 900 Lumen |
| Voltage |
230V / 110V / 42V / 24V |
Protective tube
|
polycarbonate, 40 mm Ø |
| Diffusor |
integrated |
| Handle / end cap |
PVC, black |
Suspension hook
|
rotatable hook made out of metal |
| Cable |
5 m H05RN-F 2 x 1,0 mm² (other length on request) |
| Plug |
contour plug (only 230V version) |
Protection (IP)
|
IP54 (optional IP65) |
Protection class
|
II (bzw. III) |
Length / Weight
|
510 mm / 0,750 kg |
| Ambient temperature range |
-10°C - +40°C |
Technische Daten KE-LED 3006-P
Dimensions
| |
Dimensions in mm |
| Type |
a |
b |
c |
d |
| KE-LED 4010-P/... |
510 |
56 |
40 |
240 |
Article
| Type |
Voltage |
Amp. |
Plug |
Weight |
Art.-No. |
| KE-LED 4010-P/230 |
230V AC |
0,045A |
Contour- |
0,750 kg |
131364 |
| KE-LED 4010-P/110 |
110V AC/DC |
0,050A |
w/o |
0,750 kg |
131368 |
| KE-LED 4010-P/42 |
42V AC/DC |
0,170A |
w/o |
0,750kg |
131369 |
| KE-LED 4010-P/24 |
24V AC/DC |
0,330A |
w/o |
0,750 kg |
131365 |
Accessoires
| Type |
Description |
Art.-No. |
|
| SFO-LED 4010 |
Protective film, for maintaining the protective tube with a high degree of contamination |
292700 |
|
| BFK D40 |
Fixing clamp |
290056 |
|
| KM 40 |
Fixation clamp with magnet |
291600 |
|
| SELV Trafos |
see standard accessoires |
|
|
